4 Configuration Creation | 34
To see how you can replace a measure file, watch our video Replacing Meas-
ure Files.
You can perform the following actions:
"To add a measure file" below
"To use the "Add or Replace Files" dialog" below
"To replace a measure file" on the next page
"To delete a measure file" on page36
"To delete all "No-Match" signals" on page36
"To map devices" on page36
To add a measure file
To see how you can add a measure file, save and open a configuration, or add
configuration comments, watch our video Starting to Work.
1. Select the configuration to which you want to add the measure file. If no
configuration is already open, it is created automatically when adding a
measure file.
2. Do one of the following:
l
If the respective measure file extension was linked to MDA V8 (using
Open with in Windows Explorer), just double-click the desired measure
file in your file system.
l
Drag and drop one or more measure files from your file system onto the
main window of V8.6.
l
On the Configuration tab of the ribbon, click . Select the measure
files from your file system and click Ok.
l
In the File Explorer, right-click the configuration name and select Add
Measure File(s). Select the measure files from your file system and
click Ok.
You can add the same measure file only once. Otherwise, a message is
displayed in the status bar at the bottom of the V8.6 window.
If measure files have been deleted earlier and the configuration thus
contains "No-Match" signals, a dialogue opens that allows you to either
add or replace the selected measure files. For more information, see "To
use the "Add or Replace Files" dialog" below.
To use the "Add or Replace Files" dialog
1. The dialog opens if the following prerequisites are fulfilled:
l
Measure files have been deleted earlier. The configuration thus con-
tains "No-Match" signals.
l
You have performed the steps described in "To add a measure file"
above.
