2.1.4.3. Clock Status
The right-hand side of the screen displays the status of various clocks, as follows:
Clock Status: The large virtual LED illuminates green when the H9000 is locked to either its
internal clock, or a valid external clock that you have selected for it to sync to.
The LED illuminates red if the H9000 is not locked. For example, if you have selected an
external clock source that hasn’t been connected.
USB Driver: The large virtual LED illuminates green when the H9000 has a valid USB connection
to an attached computer and will display “attached”.
The LED illuminates red if the H9000 has no valid USB connection and will display “detached”.
Sample Rate: This eld displays the actual sample rate at which H9000 is operating.
Note
The H9000 does not support sample rate conversion. If you want to feed the H9000 a digital
audio signal, the external digital signal and the H9000 must both be locked to the same digital
clock, at the same sample rate.
2.1.4.4. Word Clock Termination Status
Sets the internal word clock termination to be enabled or disabled.
Set this to “enabled” if the H9000 is at the end of a word clock chain.
Set this to “disabled” if the H9000 is in the middle of a word clock chain and a t-piece is being
used.
•
•
•
•
•
