S/PDIF/XLR/AES in 1 (Dig 1-2)
AES In 2 (Dig 3-4)
AES In 3 (Dig 5/6)
AES in 4 (Dig 7/8)
ADAT
Expansion A/B/C
Word Clock (BNC Connector)
Warning
Use a 75 ohm BNC cable. 50 ohm BNC cables may cause clocking issues.
2.1.4.2. Digital Audio Mode
The H9000 contains several dierent digital audio connectors. They are “shared” as an input source
to any given FX chain; you choose which one you wish to make active.
The Digital Audio Mode menu is where this selection is made. Use the Digital Audio mode selector to
pick your preferred connector, which will then be available in the audio routing menus of the H9000.
Available choices include:
AES 3 (DB25 Connector)
AES 3 (XLR Connector)
S/PDIF (RCA Connector)
S/PDIF (Optical Connector)
ADAT (Optical Connector)
By contrast, for the outputs, the same signal is “multed” to all of the digital audio output connectors
simultaneously.
•
•
•
•
•
•
•
•
•
•
•
•
2. Setup
Copyright © 2021, Eventide Inc.
