This 25-pin female DSUB connector feeds the H9000 with 8 channels of balanced analog audio
input. Tascam Standard pinout.
Analog Output 8-channel
This 25-pin female DSUB connector outputs 8 channels of balanced analog audio. Tascam
Standard pinout.
Note
You can adjust the operating level of the 8-channel analog inputs and outputs in the Setup
menu, between +4dBu and -10dBv. Levels can be set independently for each stereo pair of
analog inputs and outputs.
Analog Input 2-Channel
These dual balanced female XLR connectors accept two channels of balanced analog audio.
Analog Output 2-Channel
These dual balanced male XLR connectors output two channels of balanced analog audio.
MIDI Input
The MIDI input allows you to control various H9000 parameters with incoming MIDI messages,
using MIDI controller hardware or MIDI sotware of your choosing. The MIDI input also allows you
to synchronize the H9000’s time-based eects to an incoming MIDI clock signal.
MIDI Output
The MIDI Out connector outputs MIDI continuous controller messages, allowing for MIDI feedback
capabilities.
MIDI THRU
The MIDI THRU connector accepts incoming MIDI signals from the MIDI DIN input and outputs a
mirrored duplicate of those signals. This allows you to daisy chain multiple MIDI devices.
Word Clock Input
.
.
.
.
.
.
.
3. Hardware
