This BNC connector allows the H9000 to sync its digital system clock to an incoming word clock
signal. It is compatible with word clock signals ranging in sample rate from 44.1kHz to 96kHz.
Word Clock Output
This BNC connector outputs the H9000’s digital clock signal at the unit’s currently congured
sample rate.
Optical Input
The optical input accepts 8 channels of ADAT format digital audio, or 2 channels of S/PDIF
format digital audio.
Optical Output
The optical output sends 8 channels of ADAT format digital audio, or 2 channels of S/PDIF
format digital audio.
Note
The optical connectors only support sample rates of 44.1kHz and 48kHz; they are not operational
when the H9000 is set to run at higher sample rates of 88.2kHz or 96kHz.
Expansion A,B,C
These 3 slots allow for optional expansion cards detailed in Section 2.1.2: Expansion Cards.
.
.
.
.
