XRF6 RF Router Manual
CONFIGURATION Revision 1.0 Page 3-3
3.2. NETWORK CONFIGURATION MENU
The network configuration menu displays the existing network settings for the frame controller. To change
any of these values, select the appropriate number from the list, then “ENTER”, and you will be prompted
for a new value.
After changing a network setting, the new setting must be saved prior to exiting
configuration mode by selecting “(S) Save and Exit” after each change in the
network configuration.
------------------------------------------------
| Network Configuration |
| (X6RF-FC v1.00 b166) |
------------------------------------------------
------------------------------------------------
MAC: 00:02:c5:fe:cb:96
ip address: 192.168.8.1
netmask address: 255.255.255.0
gateway: 0.0.0.0
broadcast address: 192.168.8.255
DHCP enabled: False
------------------------------------------------
(1) Set IP Address
(2) Set Netmask
(3) Set Gateway
(4) Set Broadcast Address
(5) Use DHCP
(S) Save and Exit
(X) Exit
>
Each frame controller should be connected using a dedicated network in order to maximize network
performance and reliability. In systems where each frame controller is on a dedicated network, the factory
default network settings should be adequate. If the control network for the frame controller is to be
connected to an existing network, the IP address and other network settings will have to be changed so as
to be compatible with the existing network. If you are unsure how to configure your network contact your
IT network support personnel.
In frames with dual frame controller cards, each card must be configured
separately.
