7. TECHNICAL DESCRIPTION
7.1. SPECIFICATIONS
7.1.1. System
Matrix Sizes:
16x16 to 64x64 in a 6RU frame
512x512 maximum expanded system size.
System Expansion: inputs or outputs are expandable in increments of 16.
Expansion beyond 64x64 requires external distribution and combining.
Overall bandwidth: 40-2250 MHz
7.1.2. RF Specifications: L Band
Bandwidth:
850 to 2250 MHz*
Frequency Response:
+/- 1.5 dB over the passband,
+/- 0.5 dB over any 36 MHz channel
Isolation: > 60 dB ( input to output )
> 70 dB ( output to output and input to input )
RF Input Power: -10 to –70 dBm
Maximum RF Output Power: -10dBm
Input P1dB: +2 dBm ( 1500MHz ) typ
OIP3: +12dBm ( 1500MHz ) typ
Gain Range: (manual gain mode)
-6 / +20dB, maximum system output power limited to –10 dBm
Output AGC level: –20 to –50 dBm
Noise Figure: 6dB ( 1500MHz, Gain = +20dB ) typ
20dB ( 1500MHz, Gain = 0dB ) typ
Connector Type: BNC per IEC 60169-8 Amendment 2 (F connector optional)
Impedance: 75 ohm (50 ohm BNC optional)
Return Loss: > 15 dB (input and output)
* All specifications over specified bandwidth unless noted.
7.1.3. RF Specifications: If
Bandwidth:
40 to 200 MHz
Frequency Response:
+/- 0.5 dB over 50-90MHz and 120-160MHz
Isolation: > 60dB ( input to output )
> 70dB ( output to output and input to input )
RF Input Power: -15 to –70 dBm
Maximum RF Output Power: -10dBm
Input P1dB: -4 dBm ( 70MHz ) typ
OIP3:
+10dBm ( 70MHz ) typ
Gain Range: (manual gain mode)
-6 / +20dB, maximum system output power limited to –10 dBm
Return Loss: > 13 dB ( input ), > 15dB ( output )
