XRF6 RF Router Manual
Page 7-2 Revision 1.0 FIRMWARE UPGRADES
7.1.4. Communication And Control:
Serial:
RS232/RS422 selectable – Femal 9 pin D connector
Ethernet: SNMP over IEEE 802.3/U (10/100 BaseTx) RJ45 connector
Control: Card-edge interface, VistaLINK
®
7.1.5. Electrical
AC Mains Input:
Auto ranging, 100  240 VAC, 50/60 Hz
Maximum Operating Current: 2.9 A (@ 120 VAC), 1.8 A (@ 240 VAC)
Maximum Power Consumption:
300 W for a fully loaded frame
Maximum Module Load: 200 W (25 W per slot)
Power Supply Configuration: 1 supply standard, optional redundant supply requires separate inlet
Connector: IEC 60320 - 1 per power supply
Fuses:
4 amp, 250 Volt time delay 5 x 20 mm. – 2 per power supply
Status Indicators (each power supply):
PSU status LED
Local Error/Failure LED
Temperature:
0 - 40°C
7.1.6. Compliance
Safety:
CSA Listed to CSA C22.2 No. 60065-03, UL 60065-03
IEC 60065-(2001-12) 7th Edition
Complies with CE Low voltage Directive 93/68/EEC
EMC: Complies with FCC part 15, class A.
Complies with EU EMC directive 89/336/EEC
7.1.7. Physical
Height:
10.5” (266 mm)
Width: 19” (483 mm)
Depth: 20.5” (520 mm)
Module Capacity: 4 input slots, 4 output slots
Weight: Approx. 17.4 lbs. (7.9 Kg) with 2 power supplies, no slots occupied
Approx. 32 lbs. (14.5 Kg) with 2 power supplies all slots occupied
