XRF6 RF Router Manual
Page 4-2 Revision 1.0 CARD EDGE CONFIGURATION
Level 1 Level 2 Level 3 Level 4 Level 5
XRF6 I16 BACK
CH1 INPL -5 to -70dBm
…
CH16 OPL -20 to -50dBm
MODE AGC, MAN
GAIN -6 to +20 dB
SQL ON, OFF
RFTH BACK
UPPR -5 TO -30dBm
LWR -31 TO -70dBm
SQL -50 TO -70dBm
VER Displays software version
DISP VERT, HORIZ
Table 4-1: Input Card Edge Interface Menu
Individual commands are explained below:
Level 1:
Top level, displays the input card name “XRF6-I16LB”
Level 2:
CH1 –CH16: Selects which input channel is being set
VER: Displays the current input card firmware version
DISP: Used to switch between horizontal and vertical character orientation in the 4-character
display
Level 3: (specific to an individual input channel)
INPL: Displays the RF input power level of the selected channel. It displays “LOW” when the
input power level is too low to measure.
OUTL: Sets the target output power level for AGC mode (-20 to –50 dBm). This setting is only
available when the input is in AGC mode.
MODE: Sets manual or automatic gain control mode (AGC, MAN)
SQL: Sets the squelch mode to ON or OFF
RFTH: Sets the upper power alarm, lower power alarm, and squelch thresholds (UPPR, LWR,
SQL)
