XRF6 RF Router Manual
CARD EDGE CONFIGURATION Revision 1.0 Page 4-3
GAIN: Sets the system forward path gain for the input (when in manual gain mode). This setting is
only available if the input is in manual gain mode.
Levels 4 and 5:
These levels contain the range and mode parameters specific to the settings in Level 3. Refer to Table
4-1 for these values.
4.2. OUTPUT CARD EDGE INTERFACE
The output card edge pushbutton and dip switch interface is currently not supported.
