XRF6 RF Router Manual
Page 3-4 Revision 1.0 CONFIGURATION
3.3. ROUTER CONFIGURATION MENU
The router configuration menu provides access to all configuration settings for the routing matrix.
------------------------------------------------
| Router Configuration |
| (X6RF-FC v1.00 b166) |
------------------------------------------------
(1) Router input settings
(2) Router output settings
(X) Exit
>
3.3.1. Router Input Card Settings
The Router Input Settings menu provides access to all of the matrix input card settings.
------------------------------------------------
| Router input settings |
| (X6RF-FC v1.00 b166) |
------------------------------------------------
------------------------------------------------------------
Number of inputs: 16
------------------------------------------------------------
(1) Set number of router inputs
(2) Input descriptions
(3) Input gain stage mode
(4) Input gain stage target power level
(5) Input gain stage manual gain amount
(6) Input upper threshold power level
(7) Input lower threshold power level
(8) Input squelch threshold power level
(9) Input squelch enable
(10) Current input power level
(X) Exit
>
3.3.1.1. Setting The Number Of Router Inputs
The number of router inputs within a frame must be set to 16, 32, 48, or 64, depending on how many input
cards are present within the frame. The frame controller will only recognize (and control) the number of
inputs specified by this configuration setting, regardless of how many input cards are physically present in
the frame.

The frame controller recognizes matrix inputs sequentially from input card slots
from left to right in the frame, as viewed from the front. The left-most input card
slot represents inputs 1-16, while the right-most input card slot represents inputs
49-64.
