4. To modify
the LTC timecode and/or date: Type in the new timecode for the Short IN point and/or the date of
the clip in the corresponding fields.
The user-defined timecode and/or date: Type in the new timecode for the Short IN point and/or
the date of the clip in the corresponding fields.
5. (optional) To change the Primary TC, click the requested radio button:
If the User TCis selected, it is displayed in yellow on the OSD.
6. (optional) When the server is configured in 59.94 Hz (NTSC), the Drop Frame option is available.
Select the Drop Frame mode (default) or the Non-Drop Frame mode by clicking .
In 50 Hz, the Drop Frame option is not displayed.
7. Press or tap .
You can restripe the TCof a multiselection of clips at once.
Then, the restripe TCwindow will show the following elements. The TC is set to 0 and the
current date of the workstation is displayed.
116| January 2022 | Issue 1.4.G
