The following operations are allowed on a distant clip, even if the Clip Edit by Network
parameter has not been set to Yes on that server.
flag for archive
export
6.6.1.ExportingClips
Introduction
Clip angles can be exported to one or several VIA Xsquare targets.
The Export Clip function is available from the Clip Screen.
One or several VIA Xsquare targets can also be mapped to assignable Shortcut keys of the Remote
Panel for export purpose.
Prerequisite
VIA Xsquare has been configured from the Infrastructure Settings and it can be joined.
Limitation
With the current LSM-VIA version, the export can only be requested in CAMmode.
Exporting a Clip
How to Export a Local or Remote Clip from the Remote Panel Console
The clip angle loaded on the smallest controlled PGM can be exported as follows:
1. Load the clip angle to be exported on the smallest controlled PGM.
2. From the Clip screen, tap the Export Clip button:
USER MANUAL
LSM-VIA |6. Working with Clips| 127
