Unit description

Edition 09/2016

Symbol

Meaning

Splash tray

Scraper socket

(with exchangeable scraper knife)

Knife guard (to be placed onto scraper socket

during handling, mounting, mixing operation)

Scraper bolt 1mm for scraper angle 110 °

Scraper bolt 4mm for scraper angle 115 °

(by default mounted in scraper socket)

By default mounted in scraper

socket

Scraper bolt 8mm for scraper angle 120 °

Allen screwdriver 4 mm

(for mounting the scraper knife and plastic

guides working width 200 mm)
