Setup
94
27891EN-900-02 / Edition 02/2017
10.16. MOUNTING SPLASH GUARDS FOR WORKING
WIDTH 200 MM
Whenever necessary, the two splash guards (a) prevent the
product being ejected from the first roller and darting through the
room.
Fig.
: Mounting splash guard for working width 200mm
1. Undo blue or black screw, respectively, at the central unit.
2. Push in splash guards (a) and screw tight.
