7.13. SAFETY DEVICES NIP GAP AND OPTIONAL

ACCESSORIES

The following safety devices and options are available for the EXAKT 80E

Plus.

The information in "mm" refer to the working width.

The machine is always delivered with at least one safety device:

7.13.1. SAFETY DEVICES

Safety devices

Description

Nip Cover

Hopper 200 mm with plastic guides

Pull-in protection 200 mm

Safety bridge 200 mm, only for products that

are hard to process!

Hopper 170 mm

Pull-in protection 170 mm
