Exakt 80E Plus + - Dismounting the Load Traverse

Installation
60
27891EN-900-02 / Edition 02/2017
9.2. DISMOUNTING THE LOAD TRAVERSE
Allen screwdriver 6 mm
Fig.
37
: Dismounting the load traverse
› After setup, dismount the load traverse.
1. Undo 2 Allen screws (a) and remove load traverse carefully. Do not damage
the rollers in this step!
2. Mount provided 2 Allen screws M8x20 (b)
› Store load traverse with screws (a) for later transport!
b
a
