Setup
87
27891EN-900-02 / Edition 02/2017
10.12. MOUNTING PLASTIC GUIDES FOR WORKING
WIDTH 200 MM
Roller destruction due to incorrect input of the working width (E-models)
› In general, program the working width of the used safety device via the
operating unit. Else the line force values [N/mm] will not correspond.
Danger of roller destruction in force mode.
Leaks in product flow at working width 200:
The plastic guides have a blue (left plastic guide) or black screw
connection, respectively. The plastic guides wear differently. In
order to avoid leaks, the plastic guides must always be used on the
same side.
› Observe the color coding blue (left) and black (right).
› Replace worn plastic guides.
The plastic guides for the working width 200 mm consist each of the following
units:
Plastic guide shoulder roller (a), wear parts
Top for shoulder guide (b) / top for shoulder guide, hopper (b.1)
The tops (b) are each screwed onto the plastic guides (a) (wear part) (c, d)
and (c, e). The blue screw (d) or the black screw (e) help to insert the
plastic guides on the correct side into the machine
Also at the machine are a blue and a black screw on the left and right
central mount, respectively, that can be used as side orientation.
Left machine side: blue
Right machine side: black
Clamping cone for shoulder guide (f).
