Exakt 80E Plus + - Mounting the Cleaning Guard

Setup
83
27891EN-900-02 / Edition 02/2017
10.10. MOUNTING THE CLEANING GUARD
When cleaning the roller surfaces, the cleaning guard prevents body parts or
foreign objects (e.g. cleaning towel) being pulled in and thus prevents the
components being destroyed.
Allen screwdriver 6 mm
WARNING
Danger of being pulled in by the rollers during cleaning
› When cleaning, always mount the cleaning guard.
› On no account clean with other safety devices.
NOTE
Destruction of components due to being pulled into the roller gap
› When cleaning, always mount the cleaning guard. On no account clean with
other safety devices.
Fig.
56
: Mounting the cleaning guard
1. Place cleaning guard (a) from above onto the centering mounts (d).
c
b
a
d
