Setup
91
27891EN-900-02 / Edition 02/2017
3. Swivel in latch (c) and latch (d) successively.
4. Secure both latches successively with Allen screwdriver.
10.14. MOUNTING HOPPER FOR WORKING WIDTH
170 MM
Roller destruction due to incorrect input of the working width (E-models)
› In general, program the working width of the used safety device via the
operating unit. Else the line force values [N/mm] will not correspond.
Danger of roller destruction in force mode.
The hopper base (a) 170 mm is mounted the same way as other
safety devices for the nip gap. In addition, the safety guard (b) is
mounted to the hopper. The safety guard can be dismounted for
easier cleaning.
