Table of Contents
3
27891EN-900-02 / Edition 02/2017
8 Transport 51
8.1. Packaging symbols 51
8.2. Intermediate storage 52
8.3. Uncrating 52
8.4. Instructions for lifting 55
8.4.1. Moving the machine by hand 57
9 Installation 58
9.1. Setup site 58
9.2. Dismounting the load traverse 60
9.3. Mounting and aligning the operating unit 61
9.4. Connecting the electric supply 62
9.4.1. Network configuration 62
9.4.2. Connect variant 1: fixed connection 63
9.4.3. Connection variant 2: fixed connection with coded heavy
duty connector 64
9.4.4. Connection variant 3: Connection via three-poles standard
plug (min. 15A) 66
9.5. Connecting the roller temperature control 68
9.5.1. Temperature control unit 68
9.5.2. With pressureless cooling 69
9.5.3. With pressure cooling 70
9.6. Checklist installation 70
10 Setup 71
10.1. Cleaning the machine housing 71
10.2. Scraper knife types 72
10.3. Mounting the scraper knife 73
10.3.1. Combination scraper knife – scraper bar - adaptor 75
10.4. Putting on the knife guard 76
10.5. Adjusting the scraper contact pressure 77
10.6. Mounting the scraper socket 78
10.7. Aligning the scraper socket in parallel to the roller 80
10.8. Setup of the scraper angle 81
10.9. Mounting the splash tray 82
10.10. Mounting the cleaning guard 83
10.11. Inserting plastic guides for working width 85 mm and 170 mm 85
10.12. Mounting plastic guides for working width 200 mm 87
10.13. Mounting the safety device nip gap, working widths 85 mm, 170 mm,
200 mm 90
10.14. Mounting hopper for working width 170 mm 91
