9.4.2. CONNECT VARIANT 1: FIXED CONNECTION
We recommend to select a fixed connection for the unit. This connection variant
does not require a ground fault circuit interrupter and ensure proper operation.
Label (color)
Mains supply
400 V
200 V (USA, Jap.)
N (MP)
N (black)
L1
L1 (black)
L2
L2 (black)
L3
L3 (black)
PE
none (green/yellow)
PE rail
none (16 mm² green/yellow)
Eye 8 mm
