Exakt 80E Plus + - Page 58

Transport
56
27891EN-900-02 / Edition 02/2017
Fig.
34
: Lifting the machine
› The angle of the lifting rope must not exceed 60°!
Secure the lifting rope against slipping out of place (e.g. loop around the fork of
the fork lifter, see b)
› Lift the machine as horizontal and jerk-free as possible.
120 kg
265 lb
b
a
