Exakt 80E Plus +

To Next Page

To Previous Page

Installation

27891EN-900-02 / Edition 02/2017

Fig.

: Connection variant 2: fixed connection with coded heavy duty connector

Coding HARTING socket / connector

400V

Coding pin at pin 1 (socket, top view)

200V (USA, Jap)

Coding pin at pin 4 (socket, top view)
