S2000 Elite - User's Guide
035-00707 Revision 1
114
14.4. Lamp Module
Figure 1: Lamp Module
1. Reflector Rim
2. Reflector
3. Back Ceramic Mount
4. Intelli-Lamp Chip
5. Intelli-Lamp Connector
6. Power Connector
Lamp
Module
Excelitas Canada 200W Mercury DC: Standard or Surface Curing
Focal Point
of Spot
52.875 mm
Lamp
Module Life
2000 hours (guaranteed), 4000 hours typical.
Warm Up
4 minutes (min)
Lamp
Voltage
(new bulb)
60VDC nominal
Lamp
Voltage
(range)
36VDC to 95VDC
Lamp
Current
3.33A typical, 5.7A maximum
