7.1. Input/ Output Signals and Descriptions
All inputs and outputs from the PLC interface are opto-isolated. The digital outputs are
implemented using NPN logic and can be configurated as active low or active high. The digital
inputs are active low and activate on contact closure to ground. The equivalent circuit are
shown in the figures below.
PLC control signal specification:
Digital
Analogue
Input
Floating Voltage : Max 5.5VDC
Voltage: 1-5V
Current : Max 5mA
Current: Max 500uA
Output
Voltage : Max 30VDC
Voltage: 1-5V
Current : Max 8mA
Current: Max 1mA
Digital input signal requirement:
Enable
Disable
Input
Connect to
Ground
Floating
Analog input signal requirement:
Analog
Input
Intensity Setting
0-1V
Signal ignored*
1V
1%
1-5V
Conversion factor: 0.04/1%
5V
100%
