Excelitas Technologies OmniCure S2000 Elite

S2000 Elite - User's Guide
035-00707 Revision 1
91
11.3. Sample Profiles
The following StepCure profiles can be re-created using the images below, or be downloaded
and uploaded to the S2000 Elite.
Once downloaded, the intensities and durations can be modified as needed.
Example 1
Run one exposure profile once
In this example, the following
behavior occurs when the
Start/Stop button is pressed:
1. Shutter ON for 2 seconds
at 10% Intensity
2. Dwell for 2 seconds
The operation will stop after step
2
Example 2
Run one exposure profile
indefinitely
In this example, the following
behavior occurs when the
Start/Stop button is pressed:
1. Shutter ON for 2 seconds
at 10% Intensity
2. Dwell for 2 seconds
3. Repeat
The operation will not end unless
manually stopped
