Excelitas Technologies OmniCure S2000 Elite User Manual

S2000 Elite - User's Guide
035-00707 Revision 1
72
7.3. Audio Style Foot Pedal Connector: Signal Descriptions
The rear panel foot pedal connector, a 3 mm audio style jack, has the following pin-out:
Connection
Point
Signal Name
Outer Rim
Positive input, active low
Center Pin
Common ground (GND)
This is a simple 2-wire, audio style jack that can be connected to a foot pedal (supplied with
each unit) or any other electro-mechanical triggering device. This is an exposure trigger input
used to start an exposure. PLC pin 47 (Foot Pedal simulation) and front panel START/STOP
button will also trigger the shutter.
