S2000 Elite - User's Guide
035-00707 Revision 1
117
14.6. I/O Ports (including RS-232)
The S2000 Elite has five different I/O ports, four located on the back of the unit:
1. Simple 2-wire, audio style jack that can be connected to a foot pedal (supplied with
each unit) or any other electro-mechanical triggering device. This is an exposure trigger
input used to start an exposure.
2. DB50 port for PLC and RS-232 interfacing.
3. Full-Speed USB 2.0 port for connection to a computer.
4. Ethernet port to connect the system to a network - 10/100Base-T
5. RS-232 port located on the side of the front panel which is used to connect to the
R2000 Radiometer for calibration of the S2000 Elite.
