S2000 Elite - User's Guide

035-00707 Revision 1

12.2. Replacing the Air Filter

The external air filter is located under the front faceplate of the S2000 Elite.

1. Turn off the main POWER switch and remove the AC POWER cord from the unit.

2. Remove screws holding the filter cover in place and remove the filter.

3. Push in the replacement filter so that it sits flat in place and re-install filter cover.
