S2000 Elite - User's Guide
035-00707 Revision 1
116
14.5. System Specifications
Light Delivery: Flexible High Power fiber Light Guides will be available in a variety of lengths
with a variety of core diameters.
Power: 480VA Maximum
Input Power Supply: Power Factor Corrected, Universal Input
Input Voltage: 100 - 240VAC, 50/60Hz
Current: 3.5A max at 120VAC 2.0A max at 240VAC
Input Surge: 50A max. (cold start)
Protection:
• Short circuit auto-recovery
• Overvoltage (up to 135%, +/- 5% of nominal)
• EMI filtering integrated into the power supply
• Power supply has integrated thermal cut-off
Fuse Rating: Dual fuse system: each fuse rated at F4.0A 250V, 5x20mm type located in the
AC receptacle
