Introducing the FTB-1v2 and FTB-1v2 Pro

FTB-1v2 and FTB-1v2 Pro 5

Right panel

AC/DC power adapter connector

Security slot for Kensington lock

Single carrier and

FTB single-depth

module

Dual carrier and

FTB double-depth

module
