FTB-1v2 and FTB-1v2 Pro 71

4 Setting Up Your FTB-1v2 and

FTB-1v2 Pro

Adjusting Brightness

You may want to adjust the display brightness yourself to better fit your

work environment or preferences. Values are kept in memory even when

you turn the unit off.

To adjust the display brightness:

From the unit’s front panel, press the (decrease) or

(increase) button until the brightness level suits you.

The new brightness value is taken into account immediately.
