Maintenance
286 FTB-1v2 and FTB-1v2 Pro
Replacing the Battery (All Models Except High-Power Dual Carrier)
4. Place the front panel on the back panel of the unit, making sure that
the mating connector of the back panel is aligned properly with the
corresponding slot on the front. The bumpers of the back panel should
be flush with those of the front. If necessary, slightly move the front
panel until alignment is correct.
5. While holding the front and the back panels firmly together, turn the
unit over, and position it so that its front panel rests on a flat surface
such as a table.
6. Using a flat screwdriver, turn the screws (4) clockwise until they are
tightened.
This will secure the back panel into its “seated” position.
Mating connector
Connection slot for the
back panel
