Maintenance
296 FTB-1v2 and FTB-1v2 Pro
Installing or Removing the Power Meter and VFL
7. By holding the power meter by its faceplate, position it so that the VFL
is on the left.
8. Carefully align the power meter with the corresponding bay.
9. Gently slide the power meter into the bay until its faceplate is flush
with the edge of the bay. As the power meter reaches the back of the
bay, you should feel a slight resistance, indicating that it is properly
connected inside the unit.
Note: If the power meter slides all the way into the bay without any resistance, it
probably means that it is not properly inserted.
