Communicating Through TCP/IP Over Telnet

474 FTB-1v2 and FTB-1v2 Pro

Internal Commands of the TCP/IP over Telnet Protocol

STATUS MODULE

Description This command lists out all the modules with the slot

numbers where they are located (IQS-600 and

FTB-500), or with their LINS (all other platforms).

Syntax STATUS MODULE

Examples

WHO M I?

Description This command retrieves the IP address and the

communication port of the current session.

Syntax WHO M I?

Examples
