IN1608 xi Scaling Presentation Switcher • Internal Web Pages 120
3. On the confirmation dialog box, click the Overwrite button (see figure 78,
1
, on
the previous page) to erase the previous data and save the new settings, or click the
Cancel button (
2
) to return to the Preset Management page.
To recall a preset:
1. Select the input preset or user preset (see figure 77,
1
, on the previous page) to be
recalled.
2. Click the Recall Preset button (
3
) located in the same Input Presets or User
Presets panel. A confirmation dialog box opens.
3. Click the Recall button to recall the preset or click the Cancel button to return to the
Preset Management page.
To clear a preset:
1. Select the input preset or user preset (
1
) to be cleared.
2. Click the Clear button (
4
) located in the same section of the screen. A confirmation
dialog box opens.
3. Click the Clear button to erase saved data or click the Cancel button to return to the
Preset Management page.
To rename a preset:
1. Double-click a Preset Name, or right-click a Preset Name (see figure 79) and select
Rename.
Figure 79. Renaming a Preset
2. Enter a new preset name and press the <Enter> key.
