IN1608 xi Scaling Presentation Switcher • Operation 26
C
Input and output LED indicators
• Input signal LEDs — Light for each input when active video content is detected.
• Output signal LEDs — Light green when active video is being output or blink amber
when video output and sync are disabled from the scaler.
• Input HDCP LEDs — Light for each input signal that is HDCP-encrypted. Analog inputs 1
and 2 cannot be HDCP-encrypted.
• Output HDCP LEDs — Light for the active output when it is HDCP-encrypted.
D
Menu and Enter buttons — Press the Menu button to enter or exit the on-screen menu
system. Press the Enter button to select options from the on-screen menu system.
E
Navigation buttons — Press any of the four buttons to navigate the on-screen menu system
or change values of adjustable features.
F
Volume knob — Rotate this knob to adjust output, program (default), or mic volume.
Volume LEDs — Light in order from bottom to top according to the audio volume level. There
are eight LED steps from 1% (-99 dB) to 99% (-1 dB). Every quarter turn of the volume knob
equates to a one step increment (about 12.5%). When the volume is muted (0%), the bottom LED
blinks. When the volume is at 100%, the top LED blinks.
G
IPCP Pro 355 control processor LED indicators — Light to indicate the status of various
settings and connections on the IPCP Pro 355 control processor (see the IPCP Pro Series User
Guide at www.extron.com for more details).
Powering Up
When power is applied to the scaler, the input 1 button blinks green. After a few seconds,
all the input selection buttons light amber, then green while the input 1 button continues to
blink. Finally, all buttons turn off except the selected input button, which remains lit.
Input Selection
Press any of the input selection buttons on the front panel to select an input. The current
active input lights as follows:
Input Selection Button Lights
Color Signal
Amber Audio and video
Green Video only
Red Audio only
