IN1608 xi Scaling Presentation Switcher • Introduction 7
• Two bidirectional RS-232 captive screw serial ports that can control two
RS-232 devices
• One bidirectional RS-232 captive screw serial port that can communicate with one
RS-232 serially controlled device.
• Two IR/Serial ports for one-way control of external devices
• Four digital I/O ports for interfacing with other systems in the room
• Four relays for controlling room functions such as lighting, screen settings, and
other device functions.
• eBUS port for connecting eBUS button panels and accessories
• Ethernet monitoring and control of AV devices using a standard Ethernet network
• DHCP server for AV LAN automatically distributes IP addresses and network
configuration parameters for AV devices connected to the local AV LAN.
• AV LAN permits communications from the Ethernet port for remote
management and firmware updates to Extron devices. Extron devices on the
AV LAN can receive firmware updates and be remotely monitored, managed, and
controlled through Extron GlobalViewer Enterprise.
• Building Management System (BMS) protocols, such as BACnet, KNX, and DALI,
which allow for centralized monitoring and control of mechanical and electrical systems
that include HVAC, lighting, power, fire, and security.
• 10/100/1000Base-T Ethernet
• Front panel port status indicators
• Multi-level password protection allows security to be set based on user roles.
• Fully customizable using Extron control system software — GUI Designer can be
combined with Global Configurator Plus or Global Configurator Professional.
• Allows multiple IP Link Pro control processors to be grouped together to
function as one when configured with Global Configurator Professional.
• A library of enhanced Extron Certified device drivers allows Extron products to
control various display and source devices
Control Methods
Control the scalers using one or more of the following methods:
• The front panel controls and the on-screen display (OSD) menu (see On-Screen Menu
System on page 27).
• A computer, a touch screen panel, or any other device that sends and receives
serial communications through the USB, RS-232, or Ethernet port. Use the Extron
DataViewer utility on the connected device to enter SIS commands (see SIS
Configuration and Control on page 47).
• The Extron Product Configuration Software (PCS) on a computer with a Windows
®
operating system (see Configuration Software on page 77 and the IN1606 and
IN1608 Series PCS Help file).
• Internal web pages, providing a web browser-based interface for controlling the
switcher from a computer over a LAN network (see Internal Web Pages on page 88).
