IN1608 xi Scaling Presentation Switcher • Internal Web Pages 95
Switch transitions
On the Switch Transitions panel (see figure 56,
4
, on the previous page), select one of
the following radio buttons:
• Fade Through Black — Fades video to a black screen before switching to the newly
selected video.
• Cut — Switches video directly to the newly selected input.
Test patterns
To aid display device setup and optimization, select a test pattern from the Test Patterns
drop-down menu (
5
) under the preview window (see Test Pattern on page 39 for more
details).
Figure 57. Available Test Patterns
NOTE: No input signal is needed when using a test pattern for display device setup.
EDID Minder Page
EDID Minder is a management process that manages the EDID information between the
scaler and one or more input sources. Click the EDID Minder icon (see figure 54,
3
, on
page 91) on the Global Navigation Bar to open the EDID Minder page.
Figure 58. EDID Minder Page
