IN1608 xi Scaling Presentation Switcher • SIS Configuration and Control 56
Command and Response Table
Command ASCII Command
(Host to Scaler)
Response
(Scaler to Host)
Additional Description
Input Switching Commands
Input selection
Video and audio
X!
! In
X!
•All
]
Select video and audio from input
X!
.
Video only
X!
& In
X!
•RGB
]
Select video-only from input
X!
.
Audio only
X!
$ In
X!
•Aud
]
Select audio-only from input
X!
.
View video input
&
X!]
In verbose modes 2 and 3:
In
X!
•RGB
]
View the current video input.
View audio input
$
X!]
In verbose modes 2 and 3:
In
X!
•Aud
]
View the current audio input.
View current input
!
X!]
In verbose modes 2 and 3:
In
X!
•All
]
View the current video and audio
input.
NOTES:
• Audio breakaway ($) is not allowed to an input configured for any digital audio format.
• Video breakaway (&) is not allowed from an input configured for any digital audio format.
• Attempting either of these invalid modes gives an E17 error.
• Audio breakaway is always allowed back to the current video input.
Auto switch mode
Disable auto switch mode
E
0AUSW
}
Ausw0
]
Manual input switching only (default).
Prioritize highest active
input
E
1AUSW
}
Ausw1
]
Automatically switches to the highest
numbered active input.
Prioritize lowest active
input
E
2AUSW
}
Ausw2
]
Automatically switches to the lowest
numbered active input.
View auto switch mode
E
AUSW
} X5$]
In verbose modes 2 and 3:
Ausw
X5$]
View the current auto switch mode.
NOTES:
X!
= Input selection
1-8
X5$
= Auto switch mode
0 = disable (default)
1 = gives priority to the highest numbered active input
2 = gives priority to the lowest numbered active input
