IN1608 xi Scaling Presentation Switcher • SIS Configuration and Control 55
X6!
= Port number 1 = remote port (3-pole captive screw)
7 = UART** on DTP input 7
8 = UART on DTP input 8
9 = UART on DTP/HDBT output 1C
**UART = universal asynchronous receiver-
transmitter
X6@
= Baud rate
300, 600, 1200, 1800, 2400, 3600, 4800,
7200, 9600 (default), 14400, 19200, 28800,
38400, 57600, 115200
NOTE: Via PCS and the web pages, only
9600, 19200, 38400, and 115200 baud
rates are selectable.
X6#
= Parity
Odd, Even, None, Mark, Space
(Only the first letter is required.)
X6$
= Data bits
7 or 8 (default)
X6%
= Stop bits
1 (default) or 2
X6^
= Port timeout
Set in increments of 10 seconds:
1 (10 seconds) to 65000 (650,000 seconds)
Default = 30 (300 seconds)
X6&
= Start point for UART ports Controller RS-232 = port 1024
X6*
= Twisted pair (TP) format 0 = DTP format (Includes 12 VDC DTP remote
power, default)
1 = HDBaseT format
X6(
= DTP RS-232 insertion mode 0 = RS-232 pass-through – rear panel captive
screw connector (default)
1 = IP insert via UART
