IN1608 xi Scaling Presentation Switcher • Internal Web Pages 89
Turning Off Compatibility Mode
The internal web pages do not support compatibility mode in Microsoft Internet Explorer.
To check compatibility view settings:
From the Tools menu of the browser, select Compatibility View Settings. The
Compatibility View Settings dialog box opens.
Be sure that the Display all websites in Compatibility View checkbox is clear, and
that the IP address of the scaler is not in the list of websites that have been added to
Compatibility View.
AV Controls Panel
The AV Controls panel controls AV settings such as input selection, performing a one-time
Auto-Image to an input, video and audio mute, and image freeze.
At the bottom of the panel is a summary of the current active input and output status,
including signal format and HDCP status.
NOTE: This panel can be hidden or revealed on any page by clicking on the arrow
button
in the upper-right corner of the panel.
Figure 52. AV Controls Panel
The unlocked icon (see figure 52,
8
) indicates that an input or output is not HDCP-
encrypted. The lock with a check mark icon (
9
) indicates that an input or output is
HDCP-encrypted.
