IN1608 xi Scaling Presentation Switcher • Operation 27
On-Screen Menu System
The on-screen menu is used primarily for the initial setup of the device (for other methods
of control, see Control Methods on page 7). The on-screen menu presents configuration
options on a local monitor and can be adjusted with front panel controls.
NOTE: The on-screen menu has a fixed time-out of 60 seconds.
Front Panel Buttons
• Menu button — Press the Menu button to activate or exit the on-screen menu,
deselect a submenu, or cancel a pending change.
• Enter button — Press the Enter button to access the on-screen menu, select
submenus, or submenu items, or to accept pending changes.
• Navigation buttons — Press the
>
(Up) button or the
<
(Down) arrow button to
navigate submenus or submenu items. Press the (Right) arrow button to access
currently selected submenus or submenu items. Press the (Left) arrow button to
exit currently selected submenus or submenu items. You can also use the navigation
buttons to adjust settings according to specific setting directions.
• Input selection buttons — Press any of the input selection buttons to change the
selected input.
Menu Overview
In the on-screen menu, the IP address and firmware version are displayed in the top border.
The active input settings and output resolution are displayed in the bottom border. The
on-screen menu contains nine submenus with various submenu items of adjustable settings
or device information (see the table below).
Submenus Submenu Items
Quick Setup Auto-Image Input Format EDID Output
Resolution
Audio Mute Test Pattern DHCP
Mode
IP Address
User Presets Recall Save Clear
Picture Controls Image
Position
Image Size Brightness/
Contrast
Color/Tint Detail
Input Auto-Image Input Format Film Mode Start
Horizontal/
Vertical
Active
Horizontal/
Vertical
Total Pixels/
Phase
HDCP
Authorized
EDID
Output Resolution HDMI 1A
Format
HDMI 1B
Format
Out 1C Format HDCP
Notification
Audio Audio Mute Audio Format Gain Mic/Line 1:
Gain/Phantom
Mic/Line 2:
Gain/Phantom
Mic/Line
Volume
Program
Volume
Output 1/2
Format
Advanced Test Pattern Screen
Saver/
Timeout
Auto-Image Aspect Ratio Auto Memory Overscan Auto Switch Factory
Reset
Communication Remote
Port
MAC
Address
DHCP Mode IP Address Subnet Mask Gateway
Device Info
(Read Only)
Unit Name Firmware Temperature Active Input
Details
Active Output
Details
Detected
Displays
RS-232
Insertion
NOTE: The Communication submenu is normally locked. Press and hold the Enter
button for 10 seconds to unlock the submenu items.
