IN1608 xi Scaling Presentation Switcher • Internal Web Pages 127
Update Firmware Page
The Firmware Loader page provides a means of uploading firmware files to the connected
scaler. Click the Update Firmware icon (see figure 81,
5
, on page 124) on the Global
Navigation Bar to open this page.
Figure 85. Update Firmware Page
1. If necessary, download firmware updates from www.extron.com.
2. Click the Browse button (see figure 85,
1
). The Choose File to Upload window
opens.
Figure 86. Open Browse Window for Firmware Loading
3. Navigate to the firmware file location on your PC and select the firmware file. Valid
firmware files have an .eff extension.
4. Click the Open button. The window closes
5. Click the Upload button (
2
).
NOTE: The connection to the scaler may have to be reestablished.
