IN1608 xi Scaling Presentation Switcher • Configuration Software 86
Device Menu
The Device drop-down menu contains options pertaining to device connection,
configuration, and information. For details about all these options, see the IN1606 and
IN1608 Series PCS Help File.
Figure 51. Device Menu
• Disconnect — Disconnects the PCS program from the connected device and closes
the device tab.
NOTE: If a device is already disconnected, the Disconnect option is disabled until
the device is connected.
• Settings — Opens a submenu containing the following options:
• Hardware Settings — Displays the Hardware Settings dialog box containing
device information and side tabs that enable you to change the device name,
internal clock, and password of the connected device.
It also contains an Edit Communication Settings button, which provides an
alternative method of accessing the Communication Settings dialog box.
• Communication Settings — Opens the Communication Settings dialog box on
which you can change IP settings of the connected device.
• Reset Device — Opens the Reset Device dialog box, which contains selectable
modes for resetting the connected device. In addition, the Communication Settings
dialog box contains the unit information that is also displayed in the Hardware
Settings dialog box.
• Backup — Enables you to export all audio, video, and communication settings of the
connected device to the PC. This exported configuration can be saved as a backup file
(with a .estz extension), or used to replicate settings from one device to other devices
of the same model. When restoring a configuration, you can select specific device
settings.
