IN1608 xi Scaling Presentation Switcher • SIS Configuration and Control 57
Command ASCII Command
(Host to scaler)
Response
(Scaler to host)
Additional Description
Input Configuration Commands (continued)
Input video format
Set video format
X!
*
X#
\ Typ
X!
*
X#]
Set input
X!
to format
X#
.
View set format
X!
\
X#]
In verbose modes 2 and 3:
Typ
X!
*
X#]
View the set video format.
Input EDID
Assign EDID to input
E
A
X!
*
X6)
EDID
}
EdidA
X!
*
X6)]
Assign EDID
X6)
to input
X!
.
View assigned EDID
E
A
X!
EDID
} X6)]
View the EDID for input
X!
.
Save an output EDID to
custom slot
E
S
X@
*
X6)
EDID
}
EdidS
X@
*
X6)]
Save output
X@
EDID to
X6)
(3-8,
201, 202).
Export EDID file
E
E
X6)
,<filename>EDID
}
EdidE
X6)]
Export
X6)
(1-92, 201, 202) EDID.
Import EDID file
E
I
X6)
,<filename>EDID
}
Import
X6)
(3-8, 201, 202) EDID.
EdidI
X6)]
NOTES:
• EDID import and export commands use the device user file system to hold an EDID file. Use IP Link File Manager
(download IP Link File Manager from the Extron website) to move EDID files between a PC and the device user file
system.
• <filename> can optionally carry a full path name on the device user file system.
• EDID files must have an file extension of .bin, carrying 128 or 256 bytes of binary data.
• Exporting a default EDID table (for an
X5(
value of 10 or greater) results in the HDMI LPCM-2Ch table being exported.
Input name
Write input name
EX!
,
X1$
NI
}
Nmi
X!
,
X1$]
Rename input
X!
.
View input name
EX!
NI
} X1$]
View the name of input
X!
.
In verbose modes 2 and 3:
Nmi
X!
,
X1$]
NOTE: To clear an input name, enter a single space character for
X1$
. This resets the input name to the default.
NOTES:
X!
= Input selection
1-8
X#
= Input video format
1 = RGB (default for inputs 1 and 2)
2 = YUV
3 = RGBcvS
4 = S-video
5 = Composite
6 = HDMI (default for inputs 3 and higher)
X1$
= Input name (text label)
Up to 16 characters
X6)
= EDID emulation See the
X6)
definition on page 54.
