IN1608 xi Scaling Presentation Switcher • Operation 36
• HDMI or TP Output Format — After selecting HDMI 1A Format, HDMI 1B Format, or
Out 1C Format from the list of submenu items, press the navigation buttons to set the
output format. HDMI output format has three components:
• Video format — DVI or HDMI
• Color space — RGB 4:4:4, YUV 4:2:2, or YUV 4:4:4
• Quantization range — Full (0-255) or limited (16-235)
The following formats are available:
• Auto (based on display EDID) (default)
• DVI RGB 444
• HDMI RGB 444 Full
• HDMI RGB 444 Limited
• HDMI YUV 444 Full
• HDMI YUV 444 Limited
• HDMI YUV 422 Full
• HDMI YUV 422 Limited
• HDCP Notification — Press the navigation buttons to enable or disable an HDCP
compliance notification for when an HDCP-encrypted input is sent to a non-compliant
display. If HDCP notification is enabled, the output displays a green screen. If HDCP
notification is disabled, the output displays a black or muted screen.
