IN1608 xi Scaling Presentation Switcher • SIS Configuration and Control 53
X5%
= Video mute on all outputs
0 = all outputs are unmuted
1 = at least one output is muted
2 = at least one output is muted and sync is
disabled
X5^
= Volume knob group number 1 = program volume (default)
3 = mic volume
8 = output volume
X5&
= Gain or mute control 40100 = mic 1 (mix volume only)
40000 = mic 1 (mute only)
40101 = mic 2 (mix volume only)
40001 = mic 2 (mute only)
60000 = output 1
60002 = output 2
60004 = variable output L
60005 = variable output R
60006 = digital output L
60007 = digital output R
60008 = amplified output L (stereo models) or
amplified output (mono models)
60009 = amplified output R (stereo models)
X5*
= Gain or trim level -1000 to 0 = dB value multiplied by ten, in 0.1
dB increments, (for example, -100 = -10 dB)
0 = default
X5(
= HDCP mode 0 = encrypts the output only when required by
the selected input source (default)
1 = always encrypts the output, regardless of
the HDCP status of the selected input
source
2 = encrypts the output only when required by
the selected input source. Use this setting
when DVI sink devices initially pass HDCP
encrypted content, but intermittently display
a green HDCP notification screen after a
power cycle or resuming from sleep mode.
3 = always encrypts the output regardless of the
HDCP status of the selected input source.
Use this setting when DVI sink devices
initially pass HDCP encrypted content, but
intermittently display a green HDCP
notification screen after a power cycle or
resuming from sleep mode.
4 = prevents HDCP encryption and
authentication.
