8.3.2 Network
8.3.2.1 WAN Config
Field Name
Explanation
Active IP Address
The current IP address of the phone.
Current Subnet Mask
The current Subnet Mask.
Current IP Gateway
The current Gateway IP address.
MAC Address
The MAC address of the phone.
MAC Timestamp Time the MAC address was obtained.
WAN Settings
The phone supports three network modes. These are also discussed in Section 2.2.
• Static: Network parameters must be entered manually and will not change. All
parameters are provided by the ISP.
